San Hima 12V 160W Folding Solar Blanket Flexible Blanket Kit
San Hima 160W Solar Blanket – Compact Power, Built for the Outdoors
They might all look alike—lightweight, foldable, and easy to carry—but the San Hima 160W Solar Blanket is built different. With high-performance HPBC (Hybrid Passivated Back Contact) solar cell technology, it reaches an impressive 24% conversion efficiency, giving you more usable energy from every bit of sunlight.
By moving the metal contacts to the back of each cell, HPBC tech eliminates shading, absorbs more light, and performs reliably—even in the harsh heat of the Aussie outback. Topped with a rugged ETFE coating, this blanket is self-cleaning, corrosion-resistant, and designed to handle the elements.
The durable anti-crack film offers strength and flexibility for real-world use—no need to stress about bumps, heat, or wear. Pair that with the included MPPT controller, and you've got efficient charging for multiple battery types including Lead Acid, AGM, GEL, Calcium, and LiFePO4, plus USB charging ports for your devices.
Whether you're camping, hitting the road in your caravan, or setting up a remote workstation, this solar blanket is compact, powerful, and ready to keep your gear running wherever you go.
Top Features
⚡ HPBC Technology
Advanced solar cells with rear-mounted contacts for minimal shading and maximum light absorption—delivering 24% efficiency.
🧼 Self-Cleaning ETFE Coating
Non-stick, corrosion-resistant, and high-transmission—this coating keeps your panel performing longer in any environment.
🛠️ Flexible & Crack-Resistant
Engineered to withstand the rigours of outdoor life with superior tensile strength and impact resistance.
🔋 MPPT Charging Made Simple
Charges 12V/24V systems and supports a wide range of battery types. Also activates sleeping LiFePO4 batteries.
🎒 Lightweight & Compact
At just 5.1kg, this 160W blanket folds down to a handy 403 x 417 x 60mm carry bag—ready to toss in your ute, 4WD, or camper.
🛡️ Built-in Safety Protection
Stay protected with safeguards against reverse polarity, overcurrent, overvoltage, undervoltage, and short circuits.
🔌 Plug-and-Play Setup
Includes Anderson-style connectors for fast, secure, and reliable cable connections.
📱 On-the-Go Device Charging
Keep your devices powered up via USB Type A and Type C ports built into the MPPT controller.
🏕️ Designed for Adventure
Features a strong carry handle, front storage pocket, and hanging loops—ready for wherever your journey takes you.
⚠️ Note: Please avoid using a P.O. Box for delivery.
Specifications
Solar Blanket
-
Open Dimensions: 1,930 x 795 x 5 mm
-
Folded Dimensions: 403 x 417 x 60 mm
-
Cell Type: HPBC
-
Cell Coating: ETFE
-
Backing: Nylon
-
Conversion Efficiency: 24%
-
Max Power (PM): 160W
-
Open Circuit Voltage (VOC): 22.5V
-
Short Circuit Current (ISC): 9.9A
-
Max Power Voltage (VMP): 17.3V
-
Max Power Current (IMP): 9.2A
-
Max System Voltage: 36V
-
Power Tolerance: ±5%
-
Operating Temp: -40℃ to 85℃
-
Connector: Anderson-style Plug
-
Certifications: CE
-
Weight: 5.1kg
MPPT Controller
-
Battery Voltage Range: 12V / 24V
-
Max PV Input Voltage: 50V
-
Rated Charge/Discharge Current: 20A
-
Max PV Input Power: 500W
-
Discharge Voltage Drop: ≤0.3V
-
Self Consumption: ≤8mA
-
No Load Current: <10mA
-
Standby Draw: ≤4mA
-
USB Output: Type A + Type C (5V / 2.4A)
-
Operating Temp: -20℃ to 50℃
-
Storage Temp: -30℃ to 70℃
-
Humidity: ≤90%
-
Package Size: 45.6cm x 44.7cm x 11.7cm
-
Package Weight: 5.5kg
What’s Included
-
1 x San Hima 160W Solar Blanket
-
1 x 20A MPPT Solar Charge Controller (with Anderson-style plugs)
-
1 x 4.5m Extension Cable (Anderson-style)
-
1 x Alligator Clip Cable (Anderson-style plug)
-
1 x User Manual
Warranty
✅ 2-Year Warranty – Long-lasting reliability, backed by Aussie support.
